Hydraulic pumps with double pneumatic motor UPD series
A wide range of solutions that meet any type of requirements in multiple fields of application
We manufacture double stage air-hydraulic pumps with double pneumatic motor, single and double acting with pedal operation, 4-way 3-position lever hand distributor valve or remote control. Also available with a double in-line piston unit inside a single air motor for a more compact layout without loosing the high speed and the large oil flow rates which the double air motor pumps perform.
The wide range of the UPD Series can meet any requirements in multiple fields of application, from the Industry to the Automotive.
The air-hydraulic pumps of our range guarantee high performance and long durability. They can reach high working pressures up to 1000bar and large oil flow rates (l/min). The most oversized oil tank capacity of the UPD Series is 30L
The air-hydraulic pumps of the UPD Series are suitable for any hydraulic application, in multiple fields of application, especially when large oil flow rates (l/min) and high hydraulic working pressures (up to 1000bar) are required in the same hydraulic circuit.
UPFD710, air-hydraulic foot pump, double air motor, single acting, pedal operated (advance/hold/release), oil tank capacity 10L, oil flow 0.26 l/min at 700bar (2nd stage)
UPFD725, air-hydraulic foot pump, double air motor, single acting, pedal operated (advance/hold/release), oil tank capacity 25L, oil flow 0.26 l/min at 700bar (2nd stage)
UPDPF705-16/5, air-hydraulic foot pump, single air motor, double in-line piston for quick advance, single acting, pedal operated (advance/hold/release), oil tank capacity 5L, oil flow 4,29 l/min – 0,29 l/min at 250bar
UPMD710, air hydraulic pump, double air motor, double acting, air-pedal lock-up function, 4/3way lever distributor hand valve, oil tank capacity 10L, oil flow 0,26 l/min at 700bar (2° stage)
UPMD725-RC, air-hydraulic pump, double air motor, double acting, lever-operated distributor hand valve , remote control (optional), oil tank capacity 25L, oil flow 0.26 l / min at 700bar (2nd stage)
UPRDSE710, air-hydraulic pump, double air motor, single acting, 3-button remote control operation (advance/hold/release/safety), 10L oil tank capacity, 0.26 l/min oil flow at 700bar (2nd stage)
All BELL products are designed and manufactured within BELL SRL in via F. De Pisis, 5 – 42124 Reggio Emilia (RE) – Italy, according to the Quality Standards that distinguish the MADE IN ITALY from the Rest of the World.
